倒刺型接触超材料力学性能研究

田耕鑫; 曹升虎; 张健

doi:10.21656/1000-0887.440285

倒刺型接触超材料力学性能研究

doi: 10.21656/1000-0887.440285

田耕鑫¹,
曹升虎^1, ,,
张健^1,2

1. 西安理工大学土木建筑工程学院，西安 710048;
2. 西安理工大学力学实验室, 西安 710048

详细信息

作者简介:
田耕鑫（1999—），男，硕士生(E-mail: 1300907140@qq.com);曹升虎（1972—），男，副教授，博士，硕士生导师(通讯作者. E-mail: caosh@xaut.edu.cn).

通讯作者:
曹升虎（1972—），男，副教授，博士，硕士生导师(通讯作者. E-mail: caosh@xaut.edu.cn).

中图分类号: O34
计量
- 文章访问数: 57
- HTML全文浏览量: 15
- PDF下载量: 19
- 被引次数: 0
出版历程
- 收稿日期: 2023-09-20
- 修回日期: 2023-11-25
- 网络出版日期: 2024-09-30

Study on Mechanical Properties of Barbed Contact Metamaterials

1. School of Civil Engineering, Xi’an University of Technology, Xi’an 710048, P.R.China;
2. Mechanics Laboratory, Xi’an University of Technology, Xi’an 710048, P.R.China

摘要

摘要: 受到一些植物茎部和部分猫科动物舌头上的倒刺结构在不同方向上表现出差异性的启发，该研究设计了一种可重复使用且易恢复的倒刺型超材料，并对其力学性能进行了理论分析和数值分析.研究结果表明，在倒刺的往复运动中，当选取矩形截面高×宽为1 mm×1 mm，长为20 mm，且与竖直方向呈60°角的倒刺时，与阻挡凸台正向接触过程中的最大反力约为逆向接触过程中最大反力的20倍左右，而所消耗能量则相差约200倍.当倒刺与竖直方向的角度减小时，倒刺结构吸收能量更多，恢复所需能量更少；当倒刺长度增大时，倒刺结构吸收能量减小，恢复时所需能量也减小.这表明该结构具有出色的抗冲击性能和能量吸收能力，正逆向所需能量差异较大，结构更容易恢复，并且可以通过对倒刺角度和长度设计提升吸能效率.
- 仿生 /
- 各向异性 /
- 超材料 /
- 吸能 /
- 易恢复
Abstract: Inspired by the differences in the barbed structures of some plant stems and cat tongues in different directions, a reusable and easy-to-recover barbed metamaterial was designed, with its mechanical properties analyzed theoretically and numerically. The results show that, in the reciprocating motion of the barbs, when the barb rectangular section sizes are 1 mm × 1 mm, the length is 20 mm, and the angle with the vertical direction is 60°, the maximum reaction force in the forward contact process with the blocking rib will be about 20 times of the maximum reaction force in the reverse contact process, and the former energy consumption is about 200 times of the latter. With the decrease of the angle between the barb and the vertical direction, the barb structure will exhibit a higher energy absorption capacity and a reduced energy requirement for recovery. Similarly, with the increase of the barb length, the structure energy absorption will be lower and the energy required for recovery will reduce. These characteristics indicate that, the structure possesses excellent impact resistance and energy absorption capacity. Structures with significant energy disparities between forward and backward motions are more easily recoverable, and the energy absorption efficiency can be enhanced by carefully designing the angles and lengths of the barbs.
- bionic /
- anisotropic /
- metamaterial /
- energy absorption /
- easy recovery
