A Special Topic on Turbulent Combustion and Atomization

2023, 44(9): ⅰ-ⅰ.

Abstract(415) HTML (203) PDF(58)

Abstract:

Application of Enthalpy Deficit Flamelet Model in Spray Combustion Simulation

HE Junyi, LI Feng, HU Qun, WANG Lipo

2023, 44(9): 1017-1030. doi: 10.21656/1000-0887.440064

Abstract(593) HTML (286) PDF(95)

Abstract:
An OpenFOAM-based solver for spray combustion simulation with the large eddy simulation (LES) and the flamelet generated manifold (FGM) method, was developed. A simple reduction of the temperature was employed to account for the evaporative heat loss. The solver was firstly validated against the Sydney piloted ethanol spray flame benchmark EtF7. The predicted mean gas temperature and droplet statistics correspond well with the experimental data and have similar accuracy to the spray flamelet model. The turbulence-chemistry interaction modeling may have a larger influence on the simulation accuracy. Then a realistic gas turbine slinger combustor was simulated with 2 sets of operating conditions. The simulation results reveal different flame characteristics of the 2 working conditions. The predicted total pressure losses are close to the measured values.

Modelling Intermediate Species in Partially Premixed Turbulent Combustion Based on the LES-FGM Method

ZHANG Weijie, WANG Jinhua, HU Guangya, LI Deli, WANG Ziqi, HUANG Zuohua

2023, 44(9): 1031-1041. doi: 10.21656/1000-0887.440068

Abstract(635) HTML (267) PDF(80)

Abstract:
The LES of partially premixed turbulent flame MRB in TU Darmstadt was conducted based on the flamelet-tabulated combustion model FGM, and effects of premixed and partially premixed tabulations on the modelling results were studied. The results show that, different methods of tabulation exhibit limited influences on the predictions of the flame structure, velocity, and major species, but using a partially premixed tabulation largely improves the reliability of modelling intermediate minor species CO and H₂. The underlying reason lies in a better inclusion of the fuel-air mixing effects through the partially premixed tabulation, which is built based on laminar counter-flow flames. Adding extra transport equations for the intermediate species improves the predictions of intermediate species, especially given a premixed tabulation adopted; meanwhile, the stretch effects in this turbulent flame are ignorable. The results are significant to guide the high-fidelity simulation of partially premixed turbulent flames based on the flamelet-tabulated combustion model.

Numerical Analysis of Flame Flashback and Instability in Cavity-Stabilized Supersonic Combustion

XIAO Yexin, JIN Tai

2023, 44(9): 1042-1053. doi: 10.21656/1000-0887.440103

Abstract(623) HTML (235) PDF(66)

Abstract:
Aimed at the phenomenon of flame flashback and low-frequency combustion oscillation in the scramjet combustor with equal straight cross sections, 3D simulations were conducted, with the hybrid RANS/LES method (delayed detached-eddy simulation, DDES) for turbulence modeling and the partially stirred reactor (PaSR) for turbulence-reaction interactions. The obtained entire combustion oscillation period is consistent with the low-frequency combustion oscillation phenomenon observed in the experiment. The low-frequency combustion oscillation period can be divided into 3 stages: the cavity-holding flame, the flame flashback, and the flame blowout. By analysis of the reacting flow field in different stages of the low-frequency combustion oscillation cycle, the possible formation mechanism of low-frequency combustion oscillations was summarized. The results show that, there is no choking in the combustion chamber during the whole low-frequency combustion oscillation period. The pressure rise induced by shock interaction and the heat released by combustion are the key factors for the formation of low-frequency combustion oscillations in the combustion chamber.

Breakup and Atomization Characteristics of Liquid Jets in Strong Swirling Crossflow Based on the VOF-LPT Method

XIE Mingyun, PU Tianhao, LIU Hong, WU Shengqi

2023, 44(9): 1054-1069. doi: 10.21656/1000-0887.440110

Abstract(810) HTML (388) PDF(100)

Abstract:
The liquid jet breakup and atomization interacting with a strong swirling crossflow is of significance in designing advanced aeroengines. The Eulerian-Lagrangian method was utilized to simulate the jet breakup and atomization processes. The volume of fluid (VOF) method was employed to track the gas-liquid interface topology evolution during the jet breakup, while the Lagrangian particle tracing (LPT) method was used to track the discrete droplets and obtain the information on far-field liquid dispersion. The crossflow was designed with different swirl numbers, ranging from 0 to 2.5. Momentum ratio q between the liquid jet and the air flow was set to 10, and the gas Weber number was 39. Under these conditions, both the column and shear breakups were observed. The results indicate that, the development of axial waves induced by the Kevin-Helmholtz (KH) instability was the main cause for column breakup. During the surface breakup, ligaments and small liquid jet branches were stripped from the liquid jet surface, primarily driven by azimuthal shear waves. The strong swirling airflow enhances the jet column breakup process, leading to a lower radial height for the breakup location and a shorter breakup time. However, as the swirl number increases, the radial height of the onset of breakup would increase, which suggests the swirl flow would delay the surface breakup of liquid jets. With the increase of the swirl number, the velocity component in the flow direction decreases, and the jet trajectory in the radial direction increases significantly. The deflection angle of the jet shows a linear relationship with the position of the flow direction, with larger air swirl numbers resulting in a steeper slope. Furthermore, as the swirl number increases, the Sauter mean diameter (SMD) of the entire spray field would decrease, and the liquid dispersion would increase.

Low-Order Predictions of Spatial Distributions of Conserved Scalars in Swirl Combustors Based on the Gaussian Plume Function

WU Ziheng, ZHANG Chi, ZHANG Shihong, WANG Bosen

2023, 44(9): 1070-1086. doi: 10.21656/1000-0887.440119

Abstract(745) HTML (266) PDF(77)

Abstract:
The mixture fraction is a conserved scalar characterizing the fuel-air mixing. As a key reference scalar for turbulent combustion modelling, its spatial distribution is usually obtained through 3D numerical simulation, which are, however, time-consuming and costly for combustors with complex geometries. To overcome such low efficiency in the iterative designing process, a low-order model was developed based on the Gaussian plume function to compute the mixture fraction field in the swirl combustor to accelerate the evaluation of the fuel-air mixing strategy and the parameterized design process. Compared with the conventional formulation, the derived new Gaussian plume function includes the effects of convection and corrections due to swirl flows. A mirror image reflection model was further developed to simulate the wall-plume interactions, together with the relevant corrections to ensure mass conservation. This newly derived Gaussian plume model was applied to the low-older prediction of the mixture fraction field in a methane swirl combustor. Based on the database generated through 3D numerical simulations, the model parameters were optimized with the least square method first. The prediction accuracy under broad working conditions was demonstrated. This study not only provides a novel approach for quick predictions of mixture fractions in swirl combustors, but also sets an instance for further development and application of the Gaussian plume model.

Numerical Simulation Study of Spray Wall Impingement Combustion

QIN Wenjin, HAN Tianxiang, ZHANG Zhendong, SUN Yuedong

2023, 44(9): 1087-1096. doi: 10.21656/1000-0887.440077

Abstract(509) HTML (272) PDF(56)

Abstract:
Fuel spray wall impingement is a common phenomenon in small high-pressure direct injection diesel engines. Fuel spray wall impingement influences the in-cylinder combustion process, and significantly impacts the engine's dynamics, fuel economy, and emissions. To better understand the combustion characteristics of fuel spray wall impingement, the numerical simulation was applied to calculate the process and explore this process. The results show that, during the 2-stage combustion process of spray wall impingement, the impingement promotes the radial development radius and the vortex height of the spray, enhances oil-gas mixing near the wall, and forms favorable conditions for low-temperature ignition near the wall. Low-temperature combustion reactions start in the near-wall region, where the mixture is relatively dilute, and then develop into the dense mixed gas area in the center of the impinging spray. As low-temperature oxidation combustion continues to release heat, the maximum temperature in the center of the impinging spray will gradually increase, and a large amount of CH₂O will accumulate. Meanwhile, the impinging spray can cause the formation of a more concentrated mixture in the center of the impinging spray, and low-temperature combustion would release less heat, resulting in the incomplete combustion of some carbon, and increasing the amount of soot generated. Additionally, as high-temperature combustion proceeds, the temperature will continue rising, and the impinging spray will draw more oxygen, generating a large amount of NO_x through oxidation reactions.

Solid Mechanics

Influences of Impact Points on the Penetration Depth of Reinforced Concrete

HUANG Chenglong, CHEN Yeqing, LI Shutao, ZHANG Sheng, WANG Zhenqing

2023, 44(9): 1097-1111. doi: 10.21656/1000-0887.440016

Abstract(590) HTML (166) PDF(55)

Abstract:
In the research field of projectile penetration into reinforced concrete, the penetration depth discreteness generally exists in experiments and empirical formulas, and the difference of impact positions is one of the main reasons for this discreteness. To explore the penetration depth discreteness caused by the impact position difference and reveal its mechanism, the finite element models of 3 typical impact positions were established with reference to a published penetration test. The main reasons for the differences in the penetration processes of 3 typical impact positions were compared and analyzed. Based on the numerical calculation results, the expression characterizing the discreteness of penetration depth was summarized. The results show that, the penetration depth of the projectile impacting reinforced concrete is a range value. The expression was preliminarily verified. The main factors causing the penetration depth discreteness are the number of rebars hit by the projectile and the duration of contact with steel bars. This discreteness decreases with the ratio of the projectile diameter to the mesh size of rebars.
