Analytical Solutions for the Transverse Distributions of Stream-Wise Velocity in Turbulent Flow in Rectangular Channel With Partially Vegetations

HUAI Wen-xin; GENG Chuan; ZENG Yu-hong; YANG Zhong-hua

doi:10.3879/j.issn.1000-0887.2011.04.006

Volume 32 Issue 4

Turn off MathJax

Article Contents

Article Navigation > Applied Mathematics and Mechanics > 2011 > 32(4): 437-444

HUAI Wen-xin, GENG Chuan, ZENG Yu-hong, YANG Zhong-hua. Analytical Solutions for the Transverse Distributions of Stream-Wise Velocity in Turbulent Flow in Rectangular Channel With Partially Vegetations[J]. Applied Mathematics and Mechanics, 2011, 32(4): 437-444. doi: 10.3879/j.issn.1000-0887.2011.04.006

Citation:

PDF( 550 KB)

Analytical Solutions for the Transverse Distributions of Stream-Wise Velocity in Turbulent Flow in Rectangular Channel With Partially Vegetations

doi: 10.3879/j.issn.1000-0887.2011.04.006

State Key Laboratory of Water Resources and Hydropower Engineering Science, Wuhan University, Wuhan 430072, P. R. China

Received Date: 2010-10-01
Rev Recd Date: 2011-02-14
Publish Date: 2011-04-15

Abstract

Abstract

The lateral distribution of longitudinal velocity in steady uniform turbulent flow in partially vegetated rectangular channel was studied.Plants were assumed as immovable medium.The resistance caused by vegetation was expressed by the theory of poroelasticity.With the consideration of the influence of secondary flow,the momentum equation could be settled.The momentum equation was simplified due to the characters of steady uniform flow.The momentum equation was nondimensionalized to obtain a smooth solution for the lateral distribution of longitudinal velocity.The research shows the secondary current intensity coefficient is in the same order of magnitude under different flow conditions.To verify the model,the acoustic Doppler velocimeter (Micro ADV) is used to measure the velocity field in a rectangular open channel partially with emergent artificial rigid vegetation.Comparisons between the measured data,from both the experiment and the Japanese researchers' paper,and the computed results show that the method did well in predicting the transverse distributions of stream-wise velocity in turbulent flow in rectangular channel with partially vegetations.
- theory of poroelasticity,
- open channel flow,
- vegetation,
- secondary currents,
- depth-averaged

FullText(HTML)

References(18)

References

[1]	Cowna W L. Estimating hydraulic roughness coefficients[J]. Agriculture Engineering, 1956, 37(7): 473-475.
[2]	Kouwen N, Unny T E. Flexible roughness in open channels[J]. J Hydraulics Div ASCE, 1973, 99(5):713-728.
[3]	Bennett S J, Pirim T, Barkdoll B D. Using simulated emergent vegetation to alter stream flow direction within a straight experimental channel[J]. Geomorphology, 2002, 44(1/2): 115-126. doi: 10.1016/S0169-555X(01)00148-9
[4]	Liu C, Shen Y M. Flow structure and sediment transport with impacts of aquatic vegetation[J]. Journal of Hydrodynamics, Ser B, 2008, 20(4): 461-468. doi: 10.1016/S1001-6058(08)60081-5
[5]	Shimizu Y, Tsujimoto T, Nakagawa H, Kitamura T. Experimental study on flow over rigid vegetation simulated by cylinders with equi-spacing[J]. Proceedings of the Japan Society of Civil Engineer, 1991, 438(Ⅱ-17): 31-40.
[6]	Stone B M, Shen H T. Hydraulic resistance of flow in channels with cylindrical roughness[J]. Journal of Hydraulic Engineering, 2002, 128(5): 500-506. doi: 10.1061/(ASCE)0733-9429(2002)128:5(500)
[7]	Tsujimoto T, Kitamura T. Experimental study on open-channel flow with vegetated zone along side wall[C]KHL Progressive Report’92 Japan. Hydr Lab Kanazawa University, 1992: 21-35.
[8]	Wang C, Zhu P, Wang P F, Zhang W M. Effects of aquatic vegetation on flow in the Nansi lake and its flow velocity modeling[J]. Journal of Hydrodynamics, Ser B, 2006, 18(6): 640-648. doi: 10.1016/S1001-6058(07)60002-X
[9]	Wu F C, Shen H W, Chou Y J. Variation of roughness coefficients for unsubmerged and submerged vegetation[J]. Journal Hydraulic Engineering, 1999, 125(9): 934-942. doi: 10.1061/(ASCE)0733-9429(1999)125:9(934)
[10]	Yang K J, Liu X N, Cao S Y, Zhang Z X. Turbulence characteristics of overbank flow in compound river channel with vegetated floodplain[J]. Journal of Hydraulic Engineering, Ser A, 2005, 36(10): 1263-1268.
[11]	Shiono K, Knight D W. Turbulent open channel flows with variable depth across the channel[J]. Journal of Fluid Mechanics, 1991, 222(5): 617-646. doi: 10.1017/S0022112091001246
[12]	槐文信，高敏，曾玉红，李丹. 考虑滩地植被的复式断面河道水流的二维解析解[J]. 应用数学和力学， 2009, 30(9):1049-1056.(HUAI Wen-xin, GAO Min, ZENG Yu-hong, LI Dan. Two-dimensional analytical solution for compound channel flows with vegetated floodplains[J]. Applied Mathematics and Mechanics(English Edition), 2009, 30(9):1121-1130.)
[13]	Rameshwaran P, Shiono K. Quasi two-dimensional model for straight overbank flows through emergent vegetation on floodplains[J]. Journal of Hydraulic Research, 2007, 45(3): 302-315. doi: 10.1080/00221686.2007.9521765
[14]	Tang X N, Knight D W. Lateral distributions of streamwise velocity in compound channels with partially vegetated floodplains[J]. Sci China Ser E-Tech Sci, 2009, 52(11): 3357-3362. doi: 10.1007/s11431-009-0342-7
[15]	Hsieh P C, Shiu Y S. Analytical solutions for water flow passing over a vegetal area[J]. Advances in Water Resources, 2006, 29(9): 1257-1266. doi: 10.1016/j.advwatres.2005.10.004
[16]	Biot M A. Theory of propagation elastic waves in a fluid saturated porous solid—Ⅰ: low-frequency range[J]. Acoust Soc Am,1956, 28(2): 168-178. doi: 10.1121/1.1908239
[17]	Ervine D A, Babaeyan-Koopaei K, Sellin R H J. Two-dimensional solution for straight and meandering overbank flows[J]. Journal of Hydraulic Engineering, ASCE, 2000, 126(9):653-669. doi: 10.1061/(ASCE)0733-9429(2000)126:9(653)
[18]	Abril J B, Knight D W. Stage-discharge prediction for rivers in flood applying a depth-averaged mode[J]. Journal of Hydraulic Research, 2004, 42(6): 616-629. doi: 10.1080/00221686.2004.9628315
