柔性头颅模型撞击弹性板的动态响应分析

赵桂范 谭惠丰 杜星文

赵桂范, 谭惠丰, 杜星文. 柔性头颅模型撞击弹性板的动态响应分析[J]. 应用数学和力学, 2003, 24(3): 323-330.
引用本文: 赵桂范, 谭惠丰, 杜星文. 柔性头颅模型撞击弹性板的动态响应分析[J]. 应用数学和力学, 2003, 24(3): 323-330.
ZHAO Gui-fan, TAN Hui-fneg, DU Xing-wen. Method of Model Analysis for Flexible Head Impacting With Elastic Plane[J]. Applied Mathematics and Mechanics, 2003, 24(3): 323-330.
Citation: ZHAO Gui-fan, TAN Hui-fneg, DU Xing-wen. Method of Model Analysis for Flexible Head Impacting With Elastic Plane[J]. Applied Mathematics and Mechanics, 2003, 24(3): 323-330.

柔性头颅模型撞击弹性板的动态响应分析

详细信息
    作者简介:

    赵桂范(1962- ),女,吉林省松源市人,副教授,博士(E-mail:zhaoguifan@vip.sina.com).

  • 中图分类号: O322

Method of Model Analysis for Flexible Head Impacting With Elastic Plane

  • 摘要: 将柔性接触撞击过程处理为一个振动系统响应,采用机械网络图和求机械阻抗的方法解决了这一动态响应问题。柔性接触撞击模型考虑了头部的实际结构,把头部简化成撞击部位的头皮和头骨的质量、头部其它部分的头骨和脑液的质量、头部的刚度、头皮和脑液的阻尼系数组成的振动模型,弹性板也同样简化成由质量、刚度和阻尼构成的振动模型。采用求激振点速度阻抗的方法,得到了系统的动态撞击力、头部所受到的撞击加速度值,以及板的弹性变形、系统的固有频率等动态响应。实验数据与计算数据符合较好,证明方法是计算撞击作用下系统动态响应的实用方法,从而为头部撞击保护设计提供参考。
  • [1] Astuhiro S,Hirotoshi I,Robert K.Computer simulation of impact test for pedestrian protection[J].Vehicle Technology[Japan],1984,52(4):37-42.
    [2] Susan W,Enouen.The development of experimental head impact procedures for simulating pedestrian head injury[J].SAE Paper,1988,88(6):747-765.
    [3] Thomas F,Macl A,Johu F W.Pedestrian head impact against the central hood of motor vehicles-test procedure and results[J].SAE Paper,1990,2315(3):1729-1737.
    [4] Minoru S,Kzushige K,Hirotoshi I.Experimental consideration on head form impact test for pedestrian protection[J].SAE Paper,1993,0095(1):79-85.
    [5] Koji M,Janusz K,Toshiki A.Influences of vehicle shape on injuries in vehicle-pedestrian impact[J].JSAE Convention Proceedings,1999,30(4):55-60.
    [6] Koji M,Hideli Y,Janusz K.Relation between head and impact location in car-pedestrian impacts[A].In:JSAE Ed.Conference of Vehicle Technology[C].Yokohama:Japan Sven Glade H,1999,67-72.
    [7] Koji M,Hideki Y,Janusz K.The study of injury risk to the pedestrian head based on head form impact test[A].In:JSAE Ed.Spring Convention Proceedings[C].Yokohama:Japan Sven Glade H,1993,9-12.
    [8] Yasuki M,Tetsuo M,Toshiyuki A,et al.Development of FEM Models of Imp actors for Pedestrian Impact Test[A].In:JSAE Ed.Spring Convention Proceedings[C].Yokohama:Japan Sven Glade H,1999,9-12.
    [9] Akihiko A.Development of pedestrian dummy and body structure for reducing pedestrian injury[J].Vehicle Technology[Japan].1999,53(11):60-64.
    [10] Suguru Y,Norio I,Akio T,et al.Development of a body structure for reducing pedestrian injury[A].In:JSAE Ed.Spring Convention Proceedings[C].Yokohama:Japan Sven Glade H,1999,l-4.
    [11] Ruan J S,Khalil T,King A L.Human head dynamic response to side impact by finite element modeling[J].Journal of Biomechanical Engineering.1991,113(2):276-283.
    [12] Kazunari U,John W.Melvin.Finite element model study of head impact based on hybrid Ⅲ head acceleration:the effects of rotational and translational acceleration[J].Journal of Biomechanical Engineering,1995,117(2):319-328.
    [13] Ruan J S,Khalil T,King A L.Dynamic response of the human head to impact by three-dimensional finite element analysis[J].Journal of Biomechanical Engineering,1994,116(3):44-51.
    [14] Tsuyoshi Y.Application of Crash Simulation to Vehicle development[J].Vehicle Technology[Japan].1998,52(4):43-48.
    [15] 杨,唐恒龄,廖伯瑜.机床动力学[M].北京:机械工业出版社,1983.
    [16] 成祥生.应用板壳理论[M].济南:山东科学技术出版社,1989.
    [17] 焦大宾,吴文周,雷刚,等.人头颅力学模型的试验分析[A].生物力学进展[C].北京:科技出版社,1993.
    [18] 焦大宾,吴文周,杨桂通.人头颅受撞击作用的力学分析[J].中国生物医学工程学报,1992,13(9):141-149.
  • 加载中
计量
  • 文章访问数:  2078
  • HTML全文浏览量:  74
  • PDF下载量:  694
  • 被引次数: 0
出版历程
  • 收稿日期:  2001-09-18
  • 修回日期:  2002-10-10
  • 刊出日期:  2003-03-15
