转臂式离心机工作室内的瞬态温度求解与分析

尹益辉 黎启胜 郝雨 李一飞 范志庚 罗昭宇

尹益辉, 黎启胜, 郝雨, 李一飞, 范志庚, 罗昭宇. 转臂式离心机工作室内的瞬态温度求解与分析[J]. 应用数学和力学, 2020, 41(1): 81-97. doi: 10.21656/1000-0887.400047
引用本文: 尹益辉, 黎启胜, 郝雨, 李一飞, 范志庚, 罗昭宇. 转臂式离心机工作室内的瞬态温度求解与分析[J]. 应用数学和力学, 2020, 41(1): 81-97. doi: 10.21656/1000-0887.400047
YIN Yihui, LI Qisheng, HAO Yu, LI Yifei, FAN Zhigeng, LUO Zhaoyu. Research on Transient Temperature in the Work Room of a Rotary Arm Type Centrifuge[J]. Applied Mathematics and Mechanics, 2020, 41(1): 81-97. doi: 10.21656/1000-0887.400047
Citation: YIN Yihui, LI Qisheng, HAO Yu, LI Yifei, FAN Zhigeng, LUO Zhaoyu. Research on Transient Temperature in the Work Room of a Rotary Arm Type Centrifuge[J]. Applied Mathematics and Mechanics, 2020, 41(1): 81-97. doi: 10.21656/1000-0887.400047

转臂式离心机工作室内的瞬态温度求解与分析

doi: 10.21656/1000-0887.400047
基金项目: 国家自然科学基金(面上项目)(11572298);国家重大科技基础设施“超重力离心模拟与试验装置”项目
详细信息
    作者简介:

    尹益辉(1965—),男,研究员,博士,博士生导师(通讯作者. E-mail: yinyh@caep.cn).

  • 中图分类号: TH123

Research on Transient Temperature in the Work Room of a Rotary Arm Type Centrifuge

Funds: The National Natural Science Foundation of China(General Program)(11572298)
  • 摘要: 考虑大型转臂式离心机圆柱形工作室各墙壁(顶板、底板和侧壁)的瞬态导热,建立各墙壁的瞬态温度控制方程,对控制方程进行Laplace变换并求解,得到了透过墙壁内表面的总热流量与工作室内空气温度的关系.同时,综合考虑离心机驱动系统输出功率与工作室内空气和固体部件吸热、墙壁系统的吸热和导热、出风口带出的热量,以及动能与进风口带入的热量和动能之差等供能与耗能之间的平衡关系,建立工作室内瞬态温度控制方程,导出了工作室内空气瞬态温度的Laplace变换像函数的解析表达式.然后,采用求解Laplace逆变换的展开定理,导出了工作室内空气瞬态温度随时间变化的级数型显式表达式.最后,以一台多用途离心机为例,进行了工作室内空气温度的理论计算,与以前只考虑墙壁稳态导热的理论计算相比,瞬态计算结果与实测结果更加接近.所建瞬态温度公式提高了工作室温度的预测精度,有助于提升大型转臂式离心机工作室温控设计的水平.
  • [1] 贾普照. 稳态加速度模拟试验设备: 离心机概论与设计[M]. 北京: 国防工业出版社, 2013.(JIA Puzhao. Steady-State Acceleration Simulation Test Equipment: Centrifuge Conspectus and Design [M]. Beijing: National Defense Industry Press, 2013.(in Chinese))
    [2] CORTE J F. Design of geotechnical centrifuges[C]// Centrifugeuses, Equipements et Instrumentation.Paris, 1988: 9-15.
    [3] 尹益辉, 余绍蓉, 冯晓军, 等. 土工离心机的机室温升及其控制方法研究[C]//第18届全国结构工程学术会议论文集 (第Ⅰ册). 北京, 2009.(YIN Yihui, YU Shaorong, FENG Xiaojun, et al. Reseaches into temperature rise and control methods for work room of geotechnical centrifuges[C]// Proceedings of the 18th National Conference on Structural Engineering (Sesion Ⅰ).Beijing, 2009.(in Chinese))
    [4] 尹益辉, 刘远东, 王兴伦, 等. 旋臂式离心机负载转矩及其驱动电机额定功率的计算方法[J]. 机电工程, 2011,28(6): 659-662.(YIN Yihui, LIU Yuandong, WANG Xinlun, et al. Calculations of load rotational moment and rating power of centrifuges with rotation arms[J]. Journal of Mechanical & Electrical Engineering,2011,28(6): 659-662.(in Chinese))
    [5] 尹益辉, 余绍蓉, 冯晓军, 等. 密闭机室型土工离心机的风阻功率[J]. 绵阳师范学院学报, 2010,29(2): 1-5.(YIN Yihui, YU Shaorong, FENG Xiaojun, et al. Aerodynamic power of geotechnical centrifuges with closed chamber[J]. Journal of Mianyang Normal University,2010,29(2): 1-5.(in Chinese))
    [6] 尹益辉, 余绍蓉, 冯晓军, 等. 机室开有通风口的土工离心机的风阻功率[J]. 绵阳师范学院学报, 2010,29(5): 1-5.(YIN Yihui, YU Shaorong, FENG Xiaojun, et al. Aerodynamic power of geotechnical centrifuges with holed chamber[J]. Journal of Mianyang Normal University,2010,29(5): 1-5.(in Chinese))
    [7] 尹益辉, 冯晓军, 范志庚, 等. 土工离心机稳定运行时机室的自然排风效应研究[J]. 绵阳师范学院学报, 2017,36(11): 1-7.(YIN Yihui, FENG Xiaojun, FAN Zhigeng, et al. On natural air exhaust of the chamber of a steady operating geotechnical centrifuge[J]. Journal of Mianyang Normal University,2017,36(11): 1-7.(in Chinese))
    [8] 郝雨, 尹益辉, 万强, 等. 基于CFD的土工离心机风阻及流场特性分析[J]. 装备环境工程, 2018,15(2): 52-56.(HAO Yu, YIN Yihui, WAN Qiang, et al. Wind resistance and flow field characteristic analysis of geotechnical centrifuges based on CFD[J]. Equipment Environmental Engineering,2018,15(2): 52-56.(in Chinese))
    [9] 周焕林, 严俊, 余波, 等. 识别含热源瞬态热传导问题的热扩散系数[J]. 应用数学和力学, 2018,39(2): 160-169.(ZHOU Huanlin, YAN Jun, YU Bo, et al. Identification of thermal diffusion coefficients for transient heat conduction problems with heat sources[J]. Applied Mathematics and Mechanics,2018,39(2): 160-169.(in Chinese))
    [10] 陈适才, 徐珊, 张磊, 等. 火场-结构联合分析简化模型及其应用研究[J]. 应用数学和力学, 2017,38(8): 888-898.(CHEN Shicai, XU Shan, ZHANG Lei, et al. A simplified model for coupled fire-structure analysis and its application[J]. Applied Mathematics and Mechanics,2017,38(8): 888-898.(in Chinese))
    [11] 黄锦舒, 孔令刚, 韩连兵, 等. ZJU-400离心机工作舱温控效果测试与分析[C]//全国土工离心模拟技术学术交流会会议论文集. 武汉, 2011: 199-202.(HUANG Jinshu, KONG Linggang, HAN Lianbing, et al. Measurement and analysis of the temperature control effect for ZJU-400 centrifuge[C]// Proceedings of the National Conference on Simulation Technology of Geotechnical Centrifuges.Wuhan, 2011: 199-202.(in Chinese))
    [12] 四川大学数学系高等数学微分方程教研室. 高等数学[M]. 北京: 人民教育出版社, 1979.(Differential Equation Teaching and Research Section, Departments of Mathematics of Sichuan University. Higher Mathematics [M]. Beijing: People’s Education Press of China, 1979.(in Chinese))
    [13] 尹益辉, 黎启胜, 郝雨, 等. 大型旋转机械转子驱动功率的理论与实测融合分析[J]. 工程设计与力学环境, 2018(1): 16-24.(YIN Yihui, LI Qisheng, HAO Yu, et al. Combined theoretical and experimental analysis of drive power of large rotating machines[J]. Engineering Design and Mechanics Environment,2018(1): 16-24.(in Chinese))
    [14] 王照亮, 张克舫, 李华玉, 等. 一种求解复合圆筒非稳态导热问题的新方法[J]. 石油大学学报, 2005,29(2): 89-92.(WANG Zhaoliang, ZHANG Kefang, LI Huayu, et al. A new approximate solution for multiple-layer cylindrical walls of unsteady-state heat conduction[J]. Journal of the University of Petroleum,2005,29(2): 89-92.(in Chinese))
    [15] STEHFEST H. Algorithm 368 numerical inversion of Laplace transforms[J]. Communications of ACM,1970,13(1): 47-49.
