 引用本文: 刘航, 杜国君, 冯岩. 构造上正交各向异性半球形凸起凹凸板等效刚度研究[J]. 应用数学和力学, 2020, 41(1): 70-80.
LIU Hang, DU Guojun, FENG Yan. Study on Equivalent Stiffnesses of Orthotropic Hemi-Spherical Convex Plates[J]. Applied Mathematics and Mechanics, 2020, 41(1): 70-80. doi: 10.21656/1000-0887.400181
 Citation: LIU Hang, DU Guojun, FENG Yan. Study on Equivalent Stiffnesses of Orthotropic Hemi-Spherical Convex Plates[J]. Applied Mathematics and Mechanics, 2020, 41(1): 70-80.

• 中图分类号: O34

## Study on Equivalent Stiffnesses of Orthotropic Hemi-Spherical Convex Plates

• 摘要: 根据半球形凹凸板周期性将其划分得到代表性体元结构.首先研究代表性体元的刚度特性，利用变形等效原理、均质化和刚度组合法得到半球形凹凸板的等效刚度.然后将得到的三个主向刚度代入四边简支板Navier解中求解板中心挠度.通过有限元数值模拟解和Navier解进行对比分析，从而验证该文得到的主向刚度的准确性.然后讨论了代表性体元的材料尺寸对所得等效刚度的影响.随着代表性体元边长与凸起半径的比值逐渐增大，所得结果精度越来越高，且等效刚度公式适用于不同厚度的半球形凹凸板.最后给出了较为简洁的工程应用公式，并给出了凸起半径的近似取值范围和工程应用算例.
•  [1] 赵伟东, 高士武, 马宏伟. 扁球壳在热-机械荷载作用下的稳定性分析[J]. 应用数学和力学, 2017,38(10): 1146-1154.(ZHAO Weidong, GAO Shiwu, MA Hongwei. Thermomechanical stability analysis of shallow spherical shells[J]. Applied Mathematics and Mechanics,2017,38(10): 1146-1154.(in Chinese)) [2] LIAO Y, ZHAO X, ISHIDA S, et al. 〖STBX〗3D Origami Structure Design and Simulation by Parametric Origami Module [M]. Berlin: Springer, 2012. [3] YANG Y, XIA Z, ZHAO X, et al. Comprehensive Optimization for Raised Floor Structure Using Origami Engineering [M]. Berlin: Springer, 2012. [4] 郑宇宁, 邱志平, 苑凯华. 复合材料波纹板在剪切载荷下的屈曲特性分析与可靠性优化[J]. 振动与冲击, 2016,35(20): 7-14.(ZHENG Yuning, QIU Zhiping, YUAN Kaihua. Buckling performance analysis and reliability optimization of composite corrugated plates under shear loading[J]. Journal of Vibration and Shock,2016,35(20): 7-14.(in Chinese)) [5] TOKURA S, HAGIWARA I. Forming process simulation of truss core panel[J]. Journal of Computational Science ＆ Technology,2010,4(4): 25-35. [6] XIA Z Z, ZHAO X L, HAGIWARA I. A simulation approach to improve forming limitation of truss core panel[J]. Applied Mechanics and Materials,2011,121/126: 2471-2475. [7] 王光辉, 王定标, 彭旭, 等. 凹凸板的传热流阻特性及其多目标优化[J]. 工程热物理学报, 2019,40(1): 143-149.(WANG Guanghui, WANG Dingbiao, PENG Xu, et al. Heat transfer and resistance of plant heat exchanger with dimples and protrusions and optimization[J]. Journal of Engineering Thermophysics,2019,40(1): 143-149.(in Chinese)) [8] BURGESS N K, LIGRANI P M. Effects of dimple depth on channel nusselt numbers and friction factors[J]. Journal of Heat Transfer,2005,127(8): 839-847. [9] 王晓霞. 酒窝板换热特性的实验研究[D]. 硕士学位论文. 西安: 西安科技大学, 2008.(WANG Xiaoxia. Experimental study on heat transfer characteristics of dimple plates[D]. Master Thesis. Xi’an: Xi’an University of Science and Technology, 2008.(in Chinese)) [10] STROUD W J. Elastic constants for bending and twisting of corrugation stiffened panels[R]. 1963. [11] BRIASSOULIS D. Equivalent orthotropic properties of corrugated sheets[J]. Computers & Structures,1986,23(2): 129-138. [12] MCFARLAND D E. An investigation of the static stability of corrugated rectangular plates loaded in pure shear[D]. PhD Thesis. Kansas: University of Kansas, 1967. [13] WINKLER M, KRESS G. Deformation limits for corrugated cross-ply laminates[J]. Composite Structures,2010,〖STHZ〗 92(6): 1458-1468. [14] LIEW K M, PENG L X, KITIPORNCHAI S. Buckling analysis of corrugated plates using a mesh-free Galerkin method based on the first-order shear deformation theory[J]. Computational Mechanics,2006,38(1): 61-75. [15] XIA Y, FRISWELL M I, FLORES E I S. Equivalent models of corrugated panels[J]. International Journal of Solids and Structures,2012,49(13): 1453-1462. [16] 冯岩, 杜国君, 沈振兴, 等. 周期性正弦凸起凹凸板等效刚度的研究[J]. 应用数学和力学, 2019,40(5): 490-497.(FENG Yan, DU Guojun, SHEN Zhenxing, et al. Equivalent stiffness of sinusoidal periodic dimpled plates[J]. Applied Mathematics and Mechanics,2019,40(5): 490-497.(in Chinese)) [17] 冯岩, 杜国君, 赵卫东. 构造上正交各向异性凹凸板等效刚度的研究[J]. 应用力学学报, 2018,35(4): 900-905.(FENG Yan, DU Guojun, ZHAO Weidong. Equivalent stiffness research of the construction orthogonal anisotropy truss core panel[J]. Chinese Journal of Applied Mechanics,2018,35(4): 900-905.(in Chinese)) [18] 徐芝纶. 弹性力学(下册)[M]. 北京: 高等教育出版社, 2006.(XU Zhilun. Elastic Mechanics [M]. Beijing: Higher Education Press, 2006.(in Chinese)) [19] 胡肇滋, 钱寅泉. 正交构造异性板刚度计算的探讨[J]. 土木工程学报, 1987(4): 51-63.(HU Zhaozi, QIAN Yinquan. Research on the calculation of structurally orthotropic plate rigidity[J]. China Civil Engineering Journal,1987(4): 51-63.(in Chinese))
